Basic Specification

Main Circuit Power Supply
Single/three-phase 200V～240V ^+10%_- 15%，50/60Hz

Control Circuit Power Supply
Single-phase 200V～240V ^+10%_- 15%，50/60Hz

Control Mode
SVPWM、vector control

Encoder Feedback
17/20/23/24/25 bits absolute or incremental encoder

Command Mode
EtherCAT high-speed bus

Communication Function
Connect with computer (which has IMOTION software installed) via USB

Regenerative Braking Resistor
Built-in or external

Dynamic Braking
Support

Control Mode
Profile position mode (PP)、 Cycle synchronous position mode (CSP)、 Homing mode (HM)
Profile velocity mode (PV)、 Cycle synchronous velocity mode (CSV)
Profile torque mode (PT)、 Cycle synchronous torque mode (CST)
